Open End Small Scale High Production Yarn Blow

Overview

Basic Info.

Model NO.	HJ1603
Processing Material	Cotton
Producing Process	Spinning Equipment
Certification	CE, RoHS, ISO9001: 2000, REACH
Warranty	12 Months
Customized	Customized
Condition	New
Take-up Speed	20-116.7m/Min
Can Dimension	250X900, 300X900
Sliver Count	0.2-0.45nm
Combing Roller Driving	2X4.5kw
Conveyer Belt Driving	1X0.4 with Reducer
Rotor Driving	2X11
Tube Dimension	Taper Tube Cylinder Tube
Rotor Diameter	43/54/66
Drafting Ratio	35-230.5
Combing Roller Speed	5200/6200/6700/7200/7700/8200
Spindle Quantity	168
Rotor Speed	30000-75000rpm
Spindle Gauge	200
Transport Package	Wooden Package
Specification	Customized
Trademark	JTFTEX
Origin	China
HS Code	8445203200
Production Capacity	1000set/Year

Packaging & Delivery

Package Size 2500.00cm * 1000.00cm * 1200.00cm Package Gross Weight 1000.000kg

Product Description

Product Description

MODEL HJF1603 ROTOR SPINNING FRAME
Based on referring advance technology of other domestic Rotor spinning frame, HJF1603 rotor spinning frame is a sort of high speed, efficient, large package and self-exhausting open-end spinning frame.

Product Parameters

Main Technical Data:

Gauge		200
Number of units		192-360
Rotor speed(rpm)		30000-75000
Rotor dia.		43,54, 66
Combing roller speed(rpm)		5200, 6200,6700, 7200,7700, 8200
Drafting ratio		35-230.5
Sliver count		0.2-0.45nm(5000-2200tex)
Take-up speed(m/min)		20-116.7
Can diamension		250*900, 300*900, 350*900
Tube dimension		68*62*170(3°30´ taper tube) 56*50*170(cylinder tube)
Package weight		Approx 4(cylinder tube)
Motor Power(KW)	Rotor driving	2*11
	Combing rolling driving	2*4.5
	Fan for thrid hand	1*3
	Fan for impurity discharge	1*4
	Conveyer belt driving	1*1.04(with reducer)
	Gear box driving	2*1.5(drawing)+ 2*0.75(feeding)

Detailed Photos

Product processing

Product Application

Certifications

Packaging & Shipping

Company Profile

FAQ:

Q: Why Choose Our Company?
Jingtian Textile Machinery Co., Ltd. (founded in 1991) is a key backbone production enterprise in China's textile machinery manufacturing industry. It has a long history and experience in independent development and production of textile machinery products. It has a first-class R & D center and scientific and technological development team. It is an enterprise that has passed ISO9001 quality system certification earlier in the industry. At present, the company has 20 subsidiary companies with nearly 300 employees. Diversified products, standardized corporate governance structure and flexible business mechanism have injected new vitality into the development of the company.

Q: How's the after-sale service?
We offer engineers available to service overseas under merchandiser's supervision and translation.
Q: Are you available for on-the-spot invitation?We do welcome our new and old friends come here to have a visitation. Besides, we would send you our exposition and relative information to promote a face-to-face meeting if you'd like to.
Q: Is the price offered changeable?We offer reasonable price for every client, and the price is changeable according to purchasing amount.
Q: How about the quality?We have an intelligent manufacturing system.
Q: Are you a manufacturer or Trade Company?We are a professional manufacturer holding our own International Trade Department, for that we can better understand customer's needs and offer a reasonable price.
Q: Product /Quality Guarantee and After Sale Service?1 year warranty for the International standard. We are work online 24 hours. If you have any questions about our machine you can contact us.
Q: One-stop Service:We have R&D department including more than 100 engineers which are improving and enlarging our supply range.
Q: Certification?
JingTian is an ISO9001, ISO14001 company. The products are designed to meet the technical standards of 3C and CE. All the products are certified by the Industry Administration Authority. JINGTIAN will continue to strive to be a stronger leader in the global market of Cotton machinery and Spinning machinery.
